INDOOR LED DISPLAY WALL PRO Series
Indoor High Definition LED Screen
LED WALL PANEL PRO series is a new design with super thin and super light for indoor application. With premium quality & elegant appearance, multi cabinet size for flexible splicing, beveled cabinet for right angle, wall mounted, hanging, free standing with wheels, it’s the best choice for conference room, control room, airport, retail store, auditorium, theater, religion house, hospitality, shopping mall, gaming room, etc.
Cable Free Design
Faster, save labors, save time, save cost during LED screen installation. Simple, easy, convenient, user friendly.Gilding module pins, more stable data transmission, reduce defect possibility.
Superior Visual Effect
● 160°super wide viewing angle
● 7680Hz high refresh
● 10000:1 contrast ratio
● 16bit greyscale
All high configurations for better visual experience, improving definition and enhance color vibrancy, delivering lifelike details and stunningly vivid images.
Precise Aluminum Cabinet
Die casting aluminum cabinet with tolerance less than ±0.1mm, makes LED screen real seamless and perfect flatness. High strength, no distortion after long time use.
Ultra Light & Slim
33mm depth, 8kg per cabinet. 1000x500mm double sided only 53mm thickness. Solve the pain point of indoor space limitation.
Flexible Splicing
Multi-Size Options 1000x500mm, 1000x250mm, 750x250mm, 500x250mm. Vertical and horizontal cabinet installation with differ-ent cabinet size to match any LED screen size requests.
Double Sided
Only 53mm depth and 16kg/sqm makes double sided LED elegant. Perfect advertising place can help you get high ROI faster.
Cube Design
Beveled cabinet makes seamless right angle and 4 sided column LED screens. CNC professional cutting makes bevel cabinet more precise.
Wall-Mounted
LEEMAN exclusive mounting bracket, save more installation time and cost. LED screen with brackets installation depth 43mm, without brackets installation depth 33mm, super thin brings perfect appearance.
Ceiling-Mounted
Front installation, front service is good for ceiling LED screen. 16pcs strong magnets and tight module pins ensure the screen safety. Brings your venues more amazing visual experience.
Free Standing LED WALL SCREEN Poster
LED WALL Poster DISPLAY plug and play, free standing, movable, seamless cascadeall-in-one LED display. Packing in flight case, you can use the postersindividually or cascade for different events.
Hanging
Super light only 16kg/sqm and strong hanging bars ensure hanging installation without safety concern.
Front Maintenance
Anyone can replace the modules with a special suction tool. Modules, PSUreceiving cards, HUB can be fully front access and maintenance. Easy.quick, convenient, only 1 second with our cable-free design.
Parameters
| Modelo | LM1.2-PRO GOB | LM1.5-PRO GOB | LM1.9-PRO | LM2.5-PRO | LM2.6-PRO | LM2.9-PRO | LM3.9-PRO |
| Pixel Pitch(mm) | 1.25 | 1.56 | 1.95 | 2.5 | 2.6 | 2.97 | 3.91 |
| Pixel Matrix Per Sq.m | 640000 | 409600 | 262144 | 160000 | 147456 | 112896 | 65536 |
| Configuração de pixels | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD2121 |
| Brightness (nits) | ≤1000 | ≤1000 | ≤1000 | ≤1000 | ≤1000 | ≤1000 | ≤1000 |
| Scan | 1/50 | 1/40 | 1/32 | 1/25 | 1/32 | 1/28 | 1/16 |
| Dimensão do módulo | 250x250mm | 250x250mm | 250x250mm | 250x250mm | 250x250mm | 250x250mm | 250x250mm |
| Dimensão do Gabinete | 1000×500×33mm, 1000×250×33mm, 750×250×33mm, 500×250×33mm | ||||||
| Material do Gabinete | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum |
| Peso do Armário | 16KG/sqm | 16KG/sqm | 16KG/sqm | 16KG/sqm | 16KG/sqm | 16KG/sqm | 16KG/sqm |
| Power Con. (W/sqm.) | Max. 650W Avg.100~200W |
Max. 650W Avg.100~200W |
Max. 650W Avg.100~200W |
Max. 650W Avg.100~200W |
Max. 650W Avg.100~200W |
Max. 650W Avg.100~200W |
Max. 650W Avg.100~200W |
| Service Access | Full Front Access | Full Front Access | Full Front Access | Full Front Access | Full Front Access | Full Front Access | Full Front Access |
| Refresh Rate (HZ) | ≥7680 | ≥7680 | ≥7680 | ≥7680 | ≥7680 | ≥7680 | ≥7680 |
| Grey Scale (bit) | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Taxa de contraste | 10000 : 1 | 10000 : 1 | 10000 : 1 | 10000 : 1 | 10000 : 1 | 10000 : 1 | 10000 : 1 |
| Viewing Angle (H / V) | 160° / 160° | 160° / 160° | 160° / 160° | 160° / 160° | 160° / 160° | 160° / 160° | 160° / 160° |
| IP Rate | IP65 (front) | IP65 (front) | IP31 | IP31 | IP31 | IP31 | IP31 |
| Operation Temperature | ﹣30℃ ~ +60℃ | ﹣30℃ ~ +60℃ | ﹣30℃ ~ +60℃ | ﹣30℃ ~ +60℃ | ﹣30℃ ~ +60℃ | ﹣30℃ ~ +60℃ | ﹣30℃ ~ +60℃ |
| Operation Humidity | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% |
| Input Voltage (AC) | AC90-264V, 47-63Hz | AC90-264V, 47-63Hz | AC90-264V, 47-63Hz | AC90-264V, 47-63Hz | AC90-264V, 47-63Hz | AC90-264V, 47-63Hz | AC90-264V, 47-63Hz |
| * Specifications and photos are subject to change without prior notice. | |||||||
